Twitter| Business Type | Manufacturer, Exporter, Supplier, Retailer, Wholesaler |
| Type | Fully Automatic Brick Making Machine |
| Cylinder Tonnage Capacity | 150 Tonage |
| Cylinder Dia | 150 X 250 mm |
| Click to view more | |
Preferred Buyer From
| Location | Worldwide |
Product Details
Total Power
29Hp / 21.6KW
Pcs Per Stroke
6 Pcs Zigzag
Stacker System
As per requirement (Extra)
Operating System
PLC Panel Board
Main Technology
Hydraulic Hi-Pressure With Vibration
Oil Tank Capacity
400 to 450 Ltr (68 no. Hydraulic Oil)
Vibration
5000 Hz Amplitude Adjustable
Voltage Required
380V / 415V / 440V
Cycle Period
25 to 30 second colour layer per stock
Plant Dimension
L 750 cm, P 840 cm, H 300 cm
Plate Dimension
61 x 66 cm
Total Machine Weight
6750 to 7250 Kg
Production Details
| Bricks | 230 X 100 X 75 mm 10Kvt | 1800 Pcs/Hour |
| Solid & Hollow Block | 400 X 200 X 200 mm 2Kvt | 360 Pcs/Hour |
| Zigzag Paver | 220 X 112 X 80 mm 6Kvt | 720 Pcs/Hour |
| I Shape Paver | 200 X 165 X 60 mm 6Kvt | 720 Pcs/Hour |
Looking for "Fully Automatic Paver Block & Brick Making Machine" ?
